CrystalCoat 329 Polyaspartic Coating - Clear

Sale price $73.98
Size: Sample
Use this to estimate based on your floor size.
sold in last hours
In stock
Add to Wishlist
★ ★ ★ ★ ★
“Went on smooth, cured fast, no bubbles. Floors came out better than expected. Five stars from a skeptic.”
Ben T. – Verified Buyer

Fast 3–5 Business Day Delivery Direct To Site

Mixed Fresh in the USA - Guaranteed to Perform

CrystalCoat 329 Polyaspartic Coating - Clear

CrystalCoat 329 Polyaspartic Coating - Clear

Dymond CrystalCoat 329 is a high-performance, two-component 95% solids polyaspartic aliphatic sealer designed for fast-track installations where durability and minimal downtime are critical. Engineered for use as both a base coat and topcoat over decorative broadcast systems, it delivers exceptional hardness, abrasion resistance, chemical resistance, and UV stability. Its outstanding feature is its rapid return-to-service time, making it ideal for projects with tight turnaround schedules.



Key Benefits

  • 95% solids formulation for high-performance protection
  • Exceptional abrasion resistance (20 mg loss, CS-17 wheel, 1000g, 500 cycles)
  • High compressive strength (11,500 psi) and Shore D hardness of 75
  • UV stable with excellent clarity (Gardner color 1-2)
  • Fast return to service – light foot traffic in 3–5 hours
  • Suitable as both base coat and topcoat in broadcast systems



Recommended Uses

  • Medium-build decorative flake or quartz broadcast flooring systems
  • Areas requiring minimal installation downtime
  • Thin to medium build sealer over broadcasted or troweled systems



Technical Data

  • Solids by weight: 95% (+/-1%)
  • Solids by volume: 94% (+/-1%)
  • VOC: <50 g/L
  • Mix ratio: 12.95 lbs Part A to 9.3 lbs Part B (approx. 1.5 gal A : 1 gal B)
  • Recommended film thickness: 8–12 mils
  • Coverage: 133–200 sq. ft. per gallon
  • Packaging: 2.5 gallon kit (approximate net volume)
  • Application temperature: 50°F – 90°F (RH below 85%)
  • Cure time (70°F, 70% RH):
    • Tack-free: 3–4 hours
    • Recoat window: 3–5 hours
    • Light foot traffic: 3–5 hours
    • Full cure (heavy traffic): 24–48 hours

PRODUCT STORAGE: Store product at normal room temperature before use. Continuous storage should be between 60°F and 90°F. Low temperatures or temperature fluctuations may cause crystallization.


SURFACE PREPARATION: The most suitable surface preparation is a brush blast (shot blast) to remove all laitance and provide a proper surface profile. All dirt, foreign contaminants, oil, and laitance must be removed to ensure a trouble-free bond to the substrate. A moisture test should be performed to confirm the concrete is dry. This can be done by placing a 4’ x 4’ plastic sheet on the substrate and taping down the edges. If after 24 hours the surface beneath the plastic remains dry, the substrate is suitable for coating. This test also helps identify potential hydrostatic pressure issues that may later cause disbonding. For direct-to-concrete applications, testing should confirm a moisture vapor emission rate below 3 lb/24 hr/1,000 ft² per ASTM F1869.


PRODUCT MIXING: The mix ratio is 12.95 lb Part A to 9.3 lb Part B. Standard packages are pre-measured and should be mixed as supplied. After combining Parts A and B, mix thoroughly using slow-speed mixing equipment (such as a jiffy mixer) until the material is uniform and streak-free. Transfer the mixed material into a second pail and remix before application. The material is then ready for use on the properly prepared substrate.


PRIMING: A suitable primer should be used prior to application. Refer to the technical data sheet for primer recommendations. Regardless of primer use, a test patch is strongly advised to verify adhesion performance under actual service conditions.


PRODUCT APPLICATION: Apply the mixed material by brush, serrated squeegee, or roller. Maintain recommended temperature and relative humidity conditions during application and curing. The product may be used as a final topcoat to seal broadcast flake or quartz systems. Use an air release roller if required to eliminate entrapped air. Improper mixing may result in product failure. Relative humidity significantly affects cure characteristics: higher humidity shortens working time and accelerates cure, while lower humidity extends working time. Mix only quantities that can be placed within the available working time. Ensure tie-ins to previously applied material are completed within the allowable window, as previously placed material may tack off quickly.


RECOAT OR TOPCOATING: This material may be applied in multiple layers to increase build or used as the final sealing topcoat over aggregate-filled systems. Before recoating, confirm the previous layer has tacked off. Lower temperatures will extend cure time before recoating or topcoating can proceed.


CLEANUP: Use xylol.


FLOOR CLEANING: Some cleaners may affect floor color. Always test cleaning products in a small, inconspicuous area using your intended cleaning method. If no adverse effects are observed, proceed with full cleaning.


RESTRICTIONS: Restrict the floor to light traffic and non-harsh chemicals until fully cured (refer to technical data for full cure times). Keep the surface dry during the full cure cycle. Depending on the system build, surfaces may be slippery when wet or contaminated. Maintain a clean and dry surface.

The Strength of Diamond. The Confidence of a Lifetime.

Dymond Coatings are engineered with the same qualities as their namesake — tough, long-lasting, and built to bond for life. That’s why we back every eligible Dymond kit with our Lifetime Promise: if your floor fails due to a verified product defect, we’ll replace the material or issue a credit toward your next job. This warranty applies to complete Dymond systems (primer, base coat, and topcoat) when installed on indoor concrete surfaces and applied according to Dymond’s preparation and application guidelines. Covered issues include delamination caused by faulty resin blends, curing failure due to batch defects, and contamination introduced during manufacturing or packaging. To qualify, the product must be within shelf life, used under proper storage conditions, and installed using only Dymond components.

This warranty does not extend to issues arising from improper surface preparation, substrate contamination, excessive moisture vapor, impact or abuse, substrate movement, or UV discoloration of white/light epoxies. Installations over wood, tile, or outdoor surfaces are excluded unless specifically approved. Cosmetic issues such as texture variation, microbubbling, or minor tint shift are not covered. Warranty coverage is limited to the original purchaser and is non-transferable. Claims must be submitted with photographic evidence of each install stage and full batch documentation. Dymond reserves the right to determine whether the cause of failure falls within warranty scope.

This Promise applies to most DIY and light commercial indoor projects. Larger commercial and industrial installations may be eligible for custom coverage — contact us for terms.

Can This Be Installed Over My Existing Floor?

Yes, in many cases, but the floor underneath has to be clean, solid, and mechanically prepared. The coating can only bond as well as the surface it is applied to.

Every floor is different. When coating over anything other than properly prepared concrete, we strongly recommend applying a small test area first.

Bare Concrete

Best Surface

This system is designed to bond to properly prepared concrete. The concrete must be clean, dry, sound, and mechanically ground or shot blasted.

Existing Epoxy

Good With Prep

This system can be installed over an existing epoxy coating if the old coating is firmly bonded, clean, sound, and fully deglossed.

Tile

Conditional / Test First

Can be installed when tile is firmly bonded, clean, degreased, abraded, and tested first. Installation is done at your own risk.

VCT Tile

Conditional / Test First

Many customers successfully coat over VCT, but the bond depends on tile, adhesive, waxes, moisture, and movement. Installation is at your own risk.

Wood

Conditional / Scratch Coat

Requires a scratch coat first. Wood installations are done at your own risk. Always test first.

Required Surface Prep

For a strong bond, the surface must be mechanically prepared. Cleaning alone is not enough.

1

Grind or Shot Blast

The floor must be mechanically ground or shot blasted to create a surface profile the coating can grip.

2

Remove Contamination

Oil, grease, wax, soap residue, dust, old adhesive, sealers, and loose material must be removed before coating.

3

Repair Cracks & Defects

Cracks, holes, divots, and damaged areas should be filled before coating for a stronger, smoother finish.

4

Test First When Unsure

For tile, VCT, wood, unknown coatings, sealed floors, or questionable surfaces, apply a small test area.

Installation Questions We Get Every Week

Click any question to expand
? Does the floor need to be ground?

Yes. For a strong bond, the coating needs a clean, mechanically prepared surface profile.

? What does delamination mean?

Delamination is when the coating separates, peels, bubbles, or lifts from the floor underneath.

? Can this be installed over an existing epoxy?

Often yes, if the existing coating is fully bonded, clean, sound, abraded, and tested first.

? Can this be installed over VCT tile?

Sometimes, but the installation depends on the tile, adhesive, waxes, movement, and moisture. Test first.

? Can this be installed over wood?

Wood is conditional and normally needs a scratch coat. Always test first.

? Can this be installed over tile?

Tile can be conditional. It must be firmly bonded, cleaned, abraded, and tested before a full installation.

OK

Still Not Sure? Test Before You Coat.

Every floor is different. If you are coating over tile, VCT, wood, an unknown coating, sealed concrete, or a questionable surface, apply a small test area first before installing the full system.

The coating can only perform as well as the surface underneath it.

...

Have a Question We Haven't Answered?

Ask it here. Our product experts are ready and happy to help with any questions you have.

Submit My Question
i

Pro Tip: Always read the full Installation Guide and Product Data Sheets before starting your project. Proper prep is the key to a long-lasting, beautiful floor.
